Marine Air Systems 5,000 BTU Marine Boat Air Conditioner AC Unit CLM5KC-HV 207-005008

Marine Air Systems 5,000 BTU Marine Boat Air Conditioner AC Unit CLM5KC-HV 207-005008

Genuine Marine Air Systems self-contained marine air conditioning unit, model CLM5KC-HV, product number 207-005008, rated at 5,000 BTU. This compact marine AC system operates on 115V / 60Hz single-phase power and features a high-velocity blower designed for cabin cooling in compatible boats and recreational vessels.

The unit features a straight-cool configuration with a 4-inch mounting ring and utilizes R-22 refrigerant. The manufacturer's data plate identifies a 4.5-amp cooling draw, 0.91-amp fan draw, 30-amp locked rotor amperage (LRA), and an 8-ounce refrigerant charge.

This particular model was used in select marine air conditioning installations, including 2003 Chaparral Signature 240 applications. The assembly includes the compressor, evaporator coil, blower housing, refrigerant tubing, electrical components, and mounting base as pictured.

This is a used OEM marine AC unit suitable for replacement, repair, or parts applications. Buyers should verify model number, electrical requirements, dimensions, refrigerant compatibility, and installation configuration before purchase.

Highlights

  • Genuine Marine Air Systems

  • Model: CLM5KC-HV

  • Product Number: 207-005008

  • 5,000 BTU Cooling Capacity

  • 115V / 60Hz Single-Phase

  • Self-Contained Marine Air Conditioner

  • High-Velocity Blower

  • Straight-Cool Configuration

  • 4-Inch Mounting Ring

  • R-22 Refrigerant System

  • Compressor Assembly Included

  • Evaporator Cooling Coil

  • Refrigerant Tubing and Connections

  • Electrical Components and Mounting Base

  • Used in Select Chaparral Signature 240 Applications

  • Sold Exactly as Pictured

Condition

Used – Untested

  • Shows normal cosmetic wear consistent with previous marine use.

  • Metal housing and mounting base show oxidation, staining, and discoloration.

  • Evaporator coil has visible bent and uneven cooling fins.

  • Compressor exterior shows normal surface wear.

  • Refrigerant tubing and fittings show age-related discoloration and oxidation.

  • Some wiring and hoses have been cut or disconnected during removal.

  • Dust, dirt, and residue are present throughout the assembly.

  • Major exterior components appear present as pictured.

  • Unit has not been operationally tested.

  • Cooling performance, compressor operation, refrigerant charge, and electrical functionality are not guaranteed.

Please review all photographs carefully for exact condition and included components. Sold exactly as pictured.

Specifications

  • Brand: Marine Air Systems

  • Part Type: Self-Contained Marine Air Conditioner

  • Model Number: CLM5KC-HV

  • Product Number: 207-005008

  • Cooling Capacity: 5,000 BTU

  • Voltage: 115V AC

  • Frequency: 60Hz

  • Phase: Single-Phase

  • Cooling Configuration: Straight Cool

  • Blower Type: High Velocity

  • Mounting Ring: 4 Inches

  • Refrigerant: R-22

  • Refrigerant Charge: 8 oz

  • Cooling Current: 4.5 Amps

  • Fan Current: 0.91 Amps

  • Locked Rotor Amperage: 30 Amps

  • Application: Marine Cabin Air Conditioning

  • Known Application: Select 2003 Chaparral Signature 240 Installations

  • Condition: Used

  • Testing: Untested

Fitment Note: Buyer is responsible for verifying model number, product number, electrical specifications, refrigerant requirements, mounting dimensions, and compatibility with their existing marine air conditioning system. This older R-22 unit may require servicing by a qualified marine HVAC technician before installation.

Dealer Sale – Sunset Marine TX LLC

SKU: 10853


$ 360.45 $ 360.45
